Urban Form Waste Receptacle

Model Number

UFTR-30 (With Siding) UFTRAL-30 (All Aluminum)

Class-leading design combined with affordability and functionality make the Urban Form Waste Receptacle a must-have to enhance any outdoor setting. Like the rest of the Urban Form Series, the horizontal lumber orientation and minimalist look match well with modern architectural elements. Innovative features such as the keyless hidden door latch system make emptying and cleaning a breeze for any maintenance worker. Minimal fasteners and clever design mean that the recycled plastic boards can be easily replaced if damaged. The 8” opening helps deter locals from emptying their household waste and keeps out water and critters. Available with or without a foot operated pedal.

Black

Grey

Redwood

Sand

Walnut

Downloads

Urban-Form-Waste-Receptacle-Spec-Sheet.pdf

Urban Form Waste Receptacle UFTR-30.pdf

Urban Form Waste Receptacle UFTR-30.dxf

Urban Form Waste Receptacle UFTR-30.rfa

Urban Form Waste Receptacle UFTR-30.skp

Side-Mount-Cigarette-Receptacle-Spec-Sheet.pdf

CADdetails: CAD, BIM, and 3D Downloads

Product Specifications

Perma-Deck T&G Recycled Plastic Slats

The UV stabilized Re-plast recycled plastic planks are made of thermoplastic polymers (100% recycled plastic). Extremely resistant to chemical products, oil, mould and mildew, salt spray and insects. Moisture resistant, therefore will not split, rot or splinter.
Colours Available: Black, Grey, Redwood, Sand, Walnut

Durable Powder Coated Aluminum Frame

Standard Colours: Brown Slate, Victor Ridge II, Nordic Lichen, Timeless Rust, Grey Gold, Textured Silver, Precious Sand, Groovy Red, Black Textured, Earth Clay, Noble Bronze, Modern Khaki, Flame Red, Pastel Orange, Signal Violet, Traffic Yellow, Ultramarine Blue, Water Blue, Yellow Green

Long Lasting Stainless Steel Hardware

Hidden Door Latch

Easy Clean and Accessible Front Opening Design

Heavy Duty Aluminum Liner With Drain Holes

Surface Mount

Customized Solutions

Custom Powder Coating  (Setup Charges May Apply)
MFT-1 Foot pedal mechanism to open and close folding front loading door
Bottle and Can Recycler
Side Ashtray
Longboard® Woodgrain Aluminum Cladding Accents.
INST-1 Stainless Steel Bolt-Down Kit ( Installation Example )

Product Dimensions

Total Height: 42.5 inches / 107 cm
Total Depth: 23.5 inches / 60 cm
Length: 20.5 inches / 52 cm
Capacity: 36 US Gal / 137 L
Weight: 155 lbs / 70.5 kg
